Rolling Compound Machine (Adjusting Type)

TFH-TD Adjusting Type Rolling Compound Machine is the core processing equipment for broken-bridge heat-insulation aluminum profile production, and a key unit for intelligent thermal insulation profile production lines.This machine completes high-precision rolling compound of aluminum alloy profiles and PA66 thermal insulation strips, tightly integrating slotted and knurled profiles with insulation strips into high-performance heat-insulation profiles, which directly determines the composite quality, thermal insulation performance and structural strength of finished broken-bridge aluminum products.It adopts an advanced electrically controlled adjustable structure with independent cutter head lifting system, realizing wide-range flexible adjustment of cutter head spacing (0-170mm) and opening/closing height (8-80mm), perfectly adapting to profiles of different specifications and complex cross-sections. With high-quality precision components, it achieves ±0.05mm positioning accuracy, ensuring stable processing accuracy in long-term batch production. Its 6-60m/min stepless adjustable feeding speed matches both high-speed mass production and high-precision customized processing.With a compact and reasonable structure, the machine is easy to install, operate and maintain. It supports both stand-alone operation and seamless connection with slitting & threading machines to form a full automatic production system. All machines pass strict pre-shipment quality and performance tests, which can reliably meet diversified production needs, help improve efficiency, reduce labor costs, and enhance your product competitiveness.

Core processing for the production of broken-bridge heat-insulation aluminum profiles for building energy-saving doors and windows, curtain wall systems, and sunroom projects. Widely used by aluminum profile manufacturers, door and window processing enterprises, and architectural aluminum profile deep-processing factories for mass production andcustomized processing of thermal insulation profiles.Suitable for the rolling compound process of various multi-specification aluminum profiles with complex cross-sections, including industrial heat-insulation aluminum profiles and special-shaped thermal insulation profiles.Can be used as stand-alone processing equipment, or integrated into a modular automatic production line for heat-insulation profiles to realize full-process intelligent production.

1.High-Precision Electric Adjustment System: Electrically controlled 6 groups of cutter head lifting adjustment, with cutter head spacing adjustable from 0-170mm and opening/closing height adjustable from 8-80mm, flexible adjustment to fully meet diversified production needs.
2.Ultra-Stable Machining Accuracy: Adopting high-quality precision core components, with positioning accuracy up to ±0.05mm, effectively avoiding manual deviation, ensuring stable and consistent composite quality for long-term batch production.
3.Wide Adaptability & Flexible Matching: Stepless adjustable profile feeding speed of 6-60m/min, compatible with profiles with a maximum cross-section of 270×250mm, perfectly matching the complex processing conditions of various special-shaped and multi-specification profiles.
4.Optimized Structure & Easy Operation: Reasonable and compact structural design, simple operation and convenient maintenance, can realize stand-alone independent production, and can also be seamlessly connected with other equipment to form an automatic production line.
5.High Efficiency & Cost Saving: Stable and reliable continuous production capacity, effectively improving the finished product rate of profile composite processing, reducing rework rate and labor cost, which is ideal equipment for large-scale standardized production of heat-insulation profiles.
